USER'S MANUAL. RP-250
4 OPERATING INSTRUCTIONS
4.1
Description of the controls and elements
Front panel
12
13
14
15
[1]
F-F (or F-BNC or F-IEC) adapter. Output of the signals that have been activated.
[2]
"F" male base connector.
[3]
Graphic display with back lighting.
[4]
Connection to computer.
CC-RP250 specific connection cable.
Do not connect any cable other than that supplied by the
manufacturer, otherwise the instrument may suffer serious damages.
Page 11
Figure 2.- Front panel view.
1
2
3
4
5
6
7
8
9
10
11
03-2007
