5.6.1 Discharge through roof using a traditional
chimney
The chimney used to discharge the ue gas must
be made in accordance with standards UNI 10683
- EN 1856-1-2 - EN 1857 - EN 1443 - EN 13384-
1-3 - EN 12391-1 both as regards the dimensions
and the construction materials used.
DAMAGED chimneys made from unsuitable
material (asbestos cement, galvanised steel,
etc.... with a rough and porous inside surface)
are prohibited by law and affect proper stove
operation.
Makes sure connections to chimneys are suitably
sealed.
Avoid contact with combustible materials (e.g.
wooden beams) and in any case insulate these
using reproof material.
If the ues run through wooden roofs or walls,
special certi ed pass-through kits need to be used,
available on the market.
1) Vermiculite and/or rock wool.
2) Steel pipes.
3) Closure panel.
A) Chimney pot with wind protection
B) Seal
C) Inspection
00 477 5220 - 14/09/2016
1
2
3
