10 Technical data

10.1 General

Die-cast aluminium back and front cover plates
Extruded aluminium body and external slide
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws

10.2 Mechanical

Internal usable area (WxH): 134x88mm (5.1x3.5in)
Internal usable length (with or without accessories):
273mm (10.7in)
Cable glands: 3xM16
Unit weight: 4.1kg (9lb)

10.3 Housing's window

Germanium window
• Usable diameter: 55mm (2.1in)
• Thick: 2mm (0.07in)
• External treatment: scratch resistant (Hard Carbon
Coating - DLC), non-reflective
• Internal treatment: non-reflective
• Spectral range: from 7.5μm up to 14μm
• Medium transmittance (from 7.5μm up to
11.5μm): 90%
• Medium transmittance (from 11.5μm up to 14μm):
77%
10

10.4 Electrical

Supply voltage/Current consumption (version with
heater, Ton 15°C±3°C (59°F ±5°F), Toff 22°C±3°C
(72°F±5°F)):
• 12Vdc, 1.6A max
• 24Vac, 0.85A max, 50/60Hz
• 120Vac, 0.35A max, 50/60Hz
• 230Vac, 0.18A max, 50/60Hz
Camera power supply
• IN from 100Vac up to 240Vac, 50/60Hz - OUT
12Vdc, 1.25A
• IN 230Vac, 50Hz - OUT 24Vac, 50Hz, 400mA

10.5 Environment

For installation indoors and outdoors
Operating temperature with heating: from -20°C
(-4°F) up to +60°C (140°F)

10.6 Certifications

Electrical safety (CE): EN60065, EN62368-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3
IP protection degree: EN60529 (IP66/IP67, with cable
glands)
EAC certification
MNVCHTG_2104_EN
