EN
Technical data
Maximum airflow (free blowing) 140 m³/h
Min sound pressure level
Max pressure
Power consumption
Spigot depth
Hole size
Material
Protection rating
Insulation class
Voltage Frequency
Certificates
Mounting options
Bluetooth LE
Reset
Press the function button once. Press and hold
the function button for at least 5 seconds.
19 dB (A) 3 m
57 Pa
2 - 5 W
29 mm
105 - 130 mm
ABS plastic
IP44
X
100 - 240V AC 50 - 60 Hz
DC6
Wall or ceiling
- 1 2dBm EIRP (63µW),
nominal 2450MHz
Speed
Timer
Function
Humidity control
Continuous
Light
Air quality sensor
Technical data & Dimensional drawing & Reset
Settings
Press the function icon and all adjustable/programmable sym-
bols will light up. Then press any of the Timer, Humidity control,
Continuous or Light/Air quality symbols.
This will only light up the selected function, which is then ready
for adjustment. Possibility to control speed/flow
+/- is provided for certain functions. Lit lamps next to each sym-
bol indicate the function selection.
Factory settings
On delivery, Svensa has the following functions:
Continuous operation
Airing function
Timer
Automatic humidity control
Ø98
Ø118
185
approx 36m³/h*
1 hour/26 hours
approx 75m³/h*
10 minutes
approx 100m³/h*
* freeblowing
5
