Playing Different Sounds; Playing Back Demo Songs; Using A Damper Pedal - Korg SP-170 Manuel D'utilisation

Playing Different Sounds

E. Piano 2 Vibraphone
E. Organ
Piano 2
P. Organ
Clav
Harpsi
E. Piano 1
Piano 1

Playing Back Demo Songs

2 4
7 9
1 3 5 6 8 10

Using a Damper Pedal

Damper switch jack
4
The SP-170 features 10 preset sounds.
While simultaneously pressing and holding down the A # 7, B7, and C8 keys (at the right
end of the keyboard), press one of the keys ranging from C7 to A7. The preset sound
assigned to the key that you pressed will be selected.
Whenever you turn on the power to the unit, the default preset sound (Piano 1) will be
recalled.
Piano 1:
Piano 2:
E. Piano 1:
Press
these
simul-
E. Piano 2:
taneously
Harpsi:
Strings
Clav:
Vibraphone:
P. Organ:
E. Organ:
Strings:
The SP-170 features 10 demo songs that use 10 preset sounds.
Play back the demo songs to discover rich and expressive sounds.
While pressing and holding down the A # 7, B7, and C8 keys (at the right end of the key-
board), press one of the keys ranging from C6 to A6. The demo song assigned to the
key you pressed (as shown below) will start playing.
Playback starts from the selected song, then continues and repeats all demo songs in
ascending order until you stop the playback.
To stop the playback of the demo song, press the A # 7, B7, and C8 keys simultaneously.
Press
these
simul-
taneously
You can use the supplied pedal as a damper pedal by connecting it to the [DAMPER
SW] jack on the rear panel of the unit. While you press the pedal, the sound will sus-
tain, creating a rich, lingering sound.
Alternatively, you can use an optional DS-1H damper pedal. A half-pedal damper ef-
fect can be applied to Piano 1 or 2.
Elegant and warm grand piano
Clear and bright grand piano
Smooth, authentic electric piano
Modern, percussive electric piano
Classical harpsichord
Expressive electric clavichord
Smooth vibraphone
Pipe organ
Drawbar electronic organ
Ensemble string section
Demo 1 (Piano 1):
Demo 2 (Piano 2):
Demo 3 (E. Piano 1):
Demo 4 (E. Piano 2):
Demo 5 (Harpsi):
Demo 6 (Clav):
Demo 7 (Vibraphone):
Demo 8 (P. Organ) :
Demo 9 (E. Organ) :
Demo 10 (Strings) :
Fantaisie-Impromptu Op.66 /F.Chopin
Amazing Grace/unknown (arr. : N.Nishi)
Ramble /M.Sakaguchi
KORG Orignal
Invention No.8/J.S.Bach
KORG Original
KORG Original
Toccata in D moll/J.S.Bach
KORG Original
First Snow /M.Sakaguchi
