Jotul F 602 CB Installation Et Mode D'emploi page 26

US/CAN
Fig. 5
Listed Cap
Storm Collar
Flashing
Combustible
Ceiling Joists
Fig. 6
Connector pipe must
be flush with the
inside of the flue tile
Chimney
Connector
Pipe
Thimble
(Measurements in cm - for Canada)
26
Listed
Chimney
Attic
Insulation
Shield
Specified
clearance
Ceiling
to
Support
Stove
Chimney
Connector
Floor
Protector
Flue Tile
Hearth protection
Fig. 7
A
B
28 1/2"
(73 cm)
A: 8" (20 cm)
B: U.S. - 16" (41 cm)
B: CAN - 18" ( 46 cm)
Clearance to Adjacent Combustible
Fig. 8
A
B
A: 21" (53,5cm)
B: 13,5 " (34,5 cm)
Fig. 9
A
C
B
A: 13" (33,5 cm)
B: 20 1/4" (51,5cm)
Fig. 10
B
A: 24" (61 cm)
B: 19" (48,3cm)
2"
(5 cm)
A
CAN
43 1/2"
45 1/2"
A
(111 cm)
(116 cm)
A
B
C
A
