Parts List - Skandika Fitness Regatta Pro Neptun Instructions De Montage Et Mode D'emploi

Part No. Description
1 Plastic cap black
2 Foam grip
3 Handle bar grey
4 Computer
5 Spacer bar resp. Plastic bushing
6 Securing nut (M8)
7 U-shaped washer
8 Pedal black with velcro
9 Securing bolt (M6)
10 Phillips lenshead screw (ST4.2*19)
11 Phillips countersunk screw (M5*12)
12 Rowing bar
13 Phillips lenshead screw (ST4.2*10)
14 Seat
15 Mounting for the seat
16 U-shaped washer
17 Phillips lenshead screw (M6*15)
18 Plastic cap black for rear stabilizer
19 Rear stabilizer
20 Inbus screws (M8*16)
21 Phillips lenshead screw (ST4.2*19)
22 U-shaped washer
23 Rubber plug
24 Securing nut (M5)
25 Sensor mount (magnet)
26 Sensor incl. cable
27 Pin
28 Pivot
29 U-shaped washer
30 Resistance regulator
31 Adjusting knob
32 U-shaped washer
33 Hexagonal screw (M8*65)
34 Black roll (Ø 28x48)
35 Black chord
36 Cover
37 Phillips lenshead screw (M6*15)
38 Magnet bracket
39 Nut (M10)
40 Phillips lenshead screw (ST4.2*15)
41 Plastic cap black for front stabilizer
42 Front stabilizer
43 Curved u-shaped washer
Quantity Part No. Description
2 44 Phillips lenshead screw (M5*20)
2 45 Cable holder
1 46 Main frame
1 47 Hexagonal nut (M10)
2 48 Carriage bolt (M8*50)
7 49 Hexagonal nut (M6)
2 50 Pedal axle
2 51 Lenshead inbus screw (M6*10)
4 52 Front cable
4 53 U-shaped washer (Ø 6,5x18x2,0)
2 54 U-shaped washer (Ø 6,5x18x2,0)
1 55 Black roll/bushing
8 56 Lenshead inbus screw (M8)
1 57 Plastic tube
1 58 Black roller bearing
10 59 Metal axle
7 60 Magnet
2 61 Carriage bolt (M8*70)
1 62 Cap nut (M8)
2 63 Hexagonal nut (M10*1.25)
10 64 Spring washer
4 65 Fly wheel
4 66 Flexible roller right
2 67 Flat spring washer
1 68 Fly wheel axle
1 69 Flexible roller left
1 70 Tension spring
1 71 Mount support
1 72 Plastic cap
1 73 Mesh cover
1 74 Cover left
6 75 Cover right
3 76 Adjusting knob
3 77 End cap plastic
1 78 Foam grip
1 79 Lenshead inbus screw (M8*16)
2 80 Pull-up bar
1 81 Hook
2 82 Pull bar
3 83 Lenshead inbus screw (M8*90)
2 84 Black plastic ball
1 85 Bushing
4 86 Securing nut (M8)

PARTS LIST

Quantity
1
1
1
2
2
1
1
1
1
6
2
2
2
2
4
2
1
2
4
2
2
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
1
2
1
1
2
2
1
17
