ESC CALIBRATION

In order to ensure proper function, the ESC must be
calibrated to your transmitter inputs. Center the trims and
reset all settings inside the transmitter before proceeding to
the calibration

Calibration procedure

A. Make sure the ESC is switched off and then switch the
transmitter on.
B. Press and hold the setup button (located on the switch),
then switch on the ESC. Release the button as soon as the
red LED starts to flash.
C. Calibrate the throttle points by pressing the button once
after each step.
1. Neutral point (1 flash)
2. Full throttle (2 flashes)
3. Full brakes/reverse (3 flashes)
D. The motor will run 3 seconds after the last step is
completed.
