FEATURES
• Designed for on-road and off-road use
• Waterproof
• High precision speed and power control
• High power built-in BEC system for stable receiver and
servo power supply
• Easy set-up via the setup button located on the switch
• Forward and reverse function
• Several adjustable parameters
• Multiple protection systems: battery low voltage cut-off,
overheating, radio signal loss, stuck motor
CONNECTIONS
Use compatible brushless sensorless motors equipped
with 4mm bullet connectors. Respect the wire order/color
coding (ABC-blue/orange/yellow). If the motor spins in
the wrong direction reverse two of the three motor wires.
Use two batteries to power the ESC (2S/7.4V or 3S/11.1V
LiPo batteries recommended). The batteries must be
equipped with Deans® type connectors compatible with
those installed on the ESC. Using low grade batteries,
adapters or modifying the ESC connectors, can cause loss
of performance, damage, or void the warranty. Connect the
ESC receiver plug to the channel 2 of your receiver.

ESC CALIBRATION

In order to ensure proper function, the ESC must be
calibrated to your transmitter inputs. It is recommended to
center the trims and reset all settings inside the transmitter
