leave this setting on "auto calculate".
› Setting value from 2 to 6 cells 22.2V and auto-calculate
(default auto calculate)

14. BEC Voltage

This parameter sets the voltage output of the ESC BEC
system that powers the electronics on your car. WARNING!
Using 7.2V will increase the servo performance but requires
compatible electronics (regular electronics only work with
6V). Using 7.2V with 6V electronics can damage them.
› Setting value 6V or 7.2V (default 6V)

RESTORE DEFAULT SETTINGS

With the ESC powered ON and the throttle in the neutral
position, press and hold the "SET" key for 5 seconds, the red
and green LED will flash simultaneously indicating that the
parameters have been reset to the factory default values.

PROGRAM BOX

The optional program box allows you to modify all of the ESC
parameters and to modify/update the ESC firmware (via the
PC software). It is the ideal way to adjust your ESC.
• The program box is required to use the ESC in conjunction
with the PC software.
• The program box firmware is independent from the ESC
firmware. You may need to update the program box or
ESC firmware via the PC software so that they can work
together.
16 Copyright Team Orion © 2014
