Neutral Range; Timing; Motor Rotation Direction; Lipo Cells - Team Orion VORTEX R8X PRO Mode D'emploi

8. Neutral Range

This parameter adjusts the throttle sensitivity around the
neutral point. A higher value means that the throttle will
have to be moved further for the car to move forward,
backward or brake.
› Setting value from 6% to 12% (default 6%)

9. Timing

This parameter adjusts the motor drive current timing
allowing to increase performance. A lower value decreases
performance but increases efficiency and run time, a higher
value increase performance but lowers efficiency and run
time. Warning! Higher timing values cause the motor and/
or ESC to run hotter. If the motor and/or ESC overheat, they
can become damaged. USE WITH CAUTION!
› Setting value from 1 to 8 (default 5)

12. Motor Rotation Direction

This parameter allows you to change the motor rotation
direction. Note: with sensorless motors you can also switch
two of the three motor wires to change the motor rotation
direction. With sensored motors you must respect the ABC
wire order and use this setting to change the motor rotation
direction.
› Setting value CW or CCW (default CCW)

13. LiPO Cells

This parameter allows you to manually select the voltage of
the battery which is being used, overriding the automatic
detection (if you are using NiMH or LiFe batteries for
example). When using LiPo batteries It is recommended to
www.teamorion.com 15
