Thank you for purchasing a Team Orion Brushless ESC.
This ESC features the latest brushless technologies. Our
World Championship winning development team has
spent countless hours developing this ESC so that you
can experience ultimate performance. Please read these
instructions thoroughly before using the ESC.

FEATURES

• Designed for on-road and off-road 1/8 scale cars
• 6V or 7.2V adjustable BEC for more servo performance
• Works with sensor and sensorless motors
• New case design with improved cooling system
• Highly customizable software
• Easy set-up via the setup button or optional digital
program box

STATUS LED FUNCTION

• When you switch on the ESC, the green LED flashes
according to the number of cells of the battery (4 cells = 4
flashes / 4 beep tones).
• In the neutral position, no LED are lit
• The red LED lights when the car is moving forward,
backwards or is braking.

AUDIO WARNING TONES

1. Input voltage: as it is switched on the ESC checks the
input voltage and emits a number of beep tones according
to the number of battery cells detected (4 cells = 4 beep
tones). If an issue is detected, the ESC emits two beep tones
