Instructions for installation and use

10. Technical data

For the dimensions of the Concept R combi, refer to Fig. 5.
Power rating
Article
of the heating
number
system [kW]
CP-RC-090
CP-RC-105
Article Weight without
number
CP-RC-090
CP-RC-105
Fig. 5 Dimensions for Concept R combi 9 kW and 10.5 kW
WORLD OF WELLNESS
Power rating
of the evapo-
rator [kW]
9.0
10.5
Stone weight
stones [kg]
34 approx. 25
34 approx. 25
663
590
Cabin
volumes
[m 3 ]
2.5 9–14
2.5 10–15
Fuse [A]
[kg]
3 x 16
3 x 16
p. 26/26
Minimum size of
ventilation opening
[mm]
350 x 50
350 x 60
Supply
voltage
400 Vac 3N~
50/60 Hz
400 Vac 3N~
50/60 Hz
523
450
Dimensions in mm
