6.3 Sensor and Alarm installation
4-Channel
8-Channel
16-Channel
D1 – D16
Connect D1 – D16 alarm input and Ground (GND) of corresponding channel with sensor.
Alarm will be triggered once sensor causes short circuit or open circuit.
INTERNAL
CIRCUIT
1 RS 485 D -
2 RS 485 D +
3 RELAY COM
4 RELAY NC
5 RELAY NO
10 ALARM D6 15 ALARM D1
10 ALARM D14 23 ALARM D4
11 ALARM D13 24 ALARM D3
12 GND
13 ALARM D12 26 ALARM D1
58
FUNCTION
6 GND
11 ALARM D5
7 GND
12 ALARM D4
8 ALARM D8 13 ALARM D3
9 ALARM D7 14 ALARM D2
FUNCTION
1 RS 485 D -
14 ALARM D11
2 RS 485 D +
15 ALARM D10
3 GND
16 ALARM D9
4 RELAY COM 17 GND
5 RELAY NC
18 ALARM D8
6 RELAY NO
19 ALARM D7
7 GND
20 ALARM D6
8 ALARM D16 21 ALARM D5
9 ALARM D15 22 GND
25 ALARM D2
SENSOR
