4 • UK
1.3

Speciications, dimensions and capacities

1.3.1 Dimensions and capacities
Model
Discharge
Fan Type
Motor Type
Voltage V AC
RPM
Amperage Amps
Fan consumption kW
Weight
kg
Dimensions A
mm
B x B
mm
C
mm
D
mm
E
mm
Temperature Intermediate
Rating
Constant.
If fan is turned of
1.3.2 Planning ahead
1. Observe proper combustion air conditions.
2. Provide a irm support system for the chimney fan.
3. Determine the type of system involved.
4. Observe proper safety measures are taken to assure safe use of the wood burning appliances.

Combustion air requirements

Provisions for combustion air must be in accordance with applicable local codes.
Adequate fresh air must be provided for combustion, otherwise improper operation and inadequate
venting of deadly lue gases may occur.
RSHT009 RSHT012 RSHT014
Horizontal
Axial Vane
Totally enclosed, Variable speed, Class F
1x230
1360 1350 1350
0.26 0.55 1.00
0.06 0.09 0.19
11.6 15.2 19.0
298 325 372
296 364 422
275 344 395
75 85 100
220 280 330
720 °C (fan running)
500 °C (fan running)
Max. 250 °C (fan inactive)
1
2
3
4
5
6
7
8
9
10
11
12
13
3110074-RSHT-EU-DE-UK-FR-NL
RSHT016
1350
1.90
0.31
21.4
400
478
441
100
380
Capacitor and repair switch box
Conduit/cord
Motor
Motor housing
Motor plate
Bird screen
Base plate
Locking handle
Inlet
Axial vane
Hinge
Capacitor (inside box)
Cooling wheel
C
E
B
