Dimplex SmartRad Fan Convector
Models: SRX 080, SRX 120, SRX 140 & SRX 180

Important Safety Information

The heater must not be installed directly below or
in front of a permanently installed socket.
This appliance can be used by children aged 8
years and above and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
Children must not play with the appliance.
Cleaning and user maintenance must not be
made by children without supervision. Children
under 3 years should be kept away unless
continuously supervised.
Children aged from 3 to 8 years shall not plug in,
regulate or clean the appliance or perform user
maintenance. Children must only switch on/off
the appliance if it has been placed or installed in
its intended normal operating position and they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
A warning symbol is attached to the
heater. This indicates that the device
must not be covered.
CAUTION: Some parts of this product can
become hot and cause burns. Particular attention
has to be given where children and vulnerable
people are present.
IMPORTANT: If the mains cable of the device is
damaged, it must
manufacturer, a customer service representative
or a similarly qualified person.
A means for disconnection must be incorporated
in the fixed wiring in accordance with the wiring
rules and include a suitable isolator.
Install the device such that it is not possible for
someone in the bath or shower to touch the
control elements.
PLEASE STORE THESE INSTRUCTIONS IN A SAFE PLACE
be replaced by the
- 1 -
Heat output kW at flow
temperature of 45°C
Temperature range of
flow temperature (°C)
Maximum permissible
flow temperature (°C)
Permissible operating
overpressure (MPa)
Pressure drop (kPa)
Air volume flow (m³/h)
Sound pressure level at
1m (dB(A))
Nominal voltage
Power Consumption
Standby Energy
Protection category
Volume of
heat exchanger (ml)
Dimensions
W x H x D (mm)
Weight (kg)
Device description
The SmartRad is a fan convector used to heat living spaces.
The appliance is intended for connection to a central heating
system and is suitable for use in heat pump systems. It can also
be operated in conjunction with other heating systems, e.g. with
oil or gas boilers. The device draws in air from the underside,
which is heated by the heat exchanger and discharged from the
top. The SmartRad comes with a number of options E =
Electronic Model, C = Cooling option, M - White Metal Cover,
WG - White Glass Cover, BG - Black Glass Cover.
Figure 1:
(a) Casing cover
(c) Air outlet guard

Fan convectors may only be used in central heating systems
with a closed control circuit.

The heating system must be operated as a dual-pipe
system.
EN
SRX SRX SRX
080 120 140
2 0.7 1.1 1.4
25 - 85
85
1.0
11.3 13.1 13.7
3 228 345 410
2 125 190 225
1 60 100 120
47
38
27
~100-250V 50-60Hz
3 10.5 12.5 15.0
2 8 8 8
1 6 6 6
< 4 W
IP20
310 430 480
503 x 670 x 740 x
530 x 530 x 530 x
145 145 145
12 15 17.5
(b) Control panel
(d) 1 m connection cable
SRX
180
1.8
15.8
540
300
160
16.4
8
6
600
911 x
530 x
145
22
