Installation
7.6

Fitting the unit in the roof hatch

➤ Place the parking cooler centrally and facing forwards in the roof hatch
opening (fig. 9).
I
NOTE
Once the unit is in position on the vehicle roof, the seal should make contact all
the way round. Only then can a reliable seal be achieved.
➤ Position the fixing brackets underneath the cab roof (fig. 0).
When doing so, slide the fixing brackets between the cab roof (chassis) and
the roof lining.
A
NOTICE!
The fixing brackets must be positioned on a firm base since they will brace the
unit against the cab roof. The contact area of the fixing brackets must be at least
40 mm on all sides.
A
NOTICE!
Do not exceed the specified tightening torque under any circumstances. That
is the only way to ensure that the threaded plugs are not pulled out.
➤ Fix the parking cooler in place as illustrated (fig. 0).
➤ Establish the required length of the M8 hexagon-head screws as follows:
Screw length = Distance between bottom edge of fixing bracket and bottom
edge of unit plus 6 mm
If necessary, shorten the hex-head screws to the size determined.
