Installation
Sampling Head in Non-controlled Areas
9
8
7
6
Fig . 7: Sampling head set up in the non-controlled area, connected by a PVC hose (example)
No. Designation
1 Adapter or connector for
Tri-Clamp connection
2 Hose
3 Hose adapter
4 Sterile barrier
5 Sterile filters
6 Angle connector
7 Tri-Clamp (TC 50 .5) adapter
on bayonet
8 Filter adapter
9 Filter
14 MD8 Airscan Sampling Head Installation Instructions
5 4 3
Description
Connects the Tri-Clamp connection of the
sampling head to silicone hose .
PVC hose
PVC hose adapter
For example: Wall of a sterile isolator
For example: Sartofluor
with TC 50 .5
Connects Tri-Clamp (TC 50 .5) adapter to
bayonet and sterile filter .
Mount with bayonet connection
Type: Adapter for gelatine membrane filter
(GMF)
Type: Gelatine membrane filter (GMF)
2
1
capsule on both sides
®
