2) GENERAL INFORMATION

The RIGEL 6 control panel comes with standard factory settings. Any change
must be made using the programmer with built-in display or universal handheld
programmer. The Control unit completely supports the EELINK protocol.
Its main features are:
- Check of 1 or 2 single-phase motors fitted with thermostat
- Control of 1 or 2 single phase motors
Note: 2 motors of the same type must be used.
- Opening/closing limit switch control inputs, separate for each motor
- Separate inputs for safety devices
- Time band management
- Integrated obstacle detection
- Motor pre-heating with integrated sensor reading
- Adjustable electrodynamic braking
- Approach speed slow-down
- Built-in radio receiver rolling code with transmitter cloning.
The board has a terminal strip of the removable kind to make maintenance
or replacement easier. It comes with a series of prewired jumpers to make the
installer's job on site easier.
The jumpers concern terminals: 41-42, 41-43, 41-44, 41-45, 70-71, 70-72,
70-74, 76-77, 76-79, 81-82, 81-84. If the above-mentioned terminals are
being used, remove the relevant jumpers.
TESTING
The RIGEL 6 panel controls (checks) the run relays, triacs and safety devices (pho-
tocells and edges), before performing each opening and closing cycle.
If there is a malfunction, make sure that the connected devices are working
properly and check the wiring.
ATTENTION! if the leaf is installed in a public area or if an automatic operating
mode is enabled, we recommend a pair of photocells is installed at a height of 5
cm together with another pair at a height of 40-50 cm. Automatic mode means any
control not voluntarily activated by the user (example: TCA function, chrono, etc.)

3) TECHNICAL SPECIFICATIONS

Power supply
Low voltage/mains insulation
Dielectric rigidity
Accessories power supply
Terminal
L
N
GND
10
11
12
14
15
16
110-120 / 220-230 V~
20
POWERED CONTACT
21
110-120 / 220-230 V~
22
POWERED CONTACT
23
24
AUX 2 - FREE CONTACT
25
26
AUX 3 - FREE CONTACT
27
28
29
40
41
42
43
44
45
50
51
52
40
- RIGEL 6
INSTALLATION MANUAL
110-120V 50/60Hz
220-230V 50/60Hz
> 2MOhm 500V
mains/LV 3750V~ for 1 minute
24V~ (demand max. 1A)
24V~safe
Definition
LINE
Single-phase power supply
NEUTRAL 110-120V 50/60Hz
220-230V 50/60Hz
EARTH
MOT1 RUN
MOT 1 COM Connection motor 1. Time lag during closing.
MOT1 RUN
MOT2 RUN
Connection motor 2. Time lag during opening.
MOT 2 COM
Note: if "1 MOT. O N. " = 1 do not connect any wires to terminals 14-15-16
MOT2 RUN
AUX 0 configurable output - Default setting FLASHING LIGHT.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output configuration" table.
AUX 1 configurable output - Default setting ZONE LIGHT Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output configuration" table.
AUX 2 configurable output - Default setting SCA GATE OPEN LIGHT Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
(N.O.)
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output configuration" table.
AUX 3 configurable output - Default setting MONOSTABLE RADIO CHANNEL Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
(N.O.)
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output configuration" table.
Type of lock logic= 0 - 12V
Output activated with a pulse each time gate is opened or closed
LOCK 12V
Type of lock logic= 1 - 12V
Output activated when gate is closed or closing
Not used
+ REF SWE Limit switch common
SWC 1 Motor 1 closing limit switch SWC1 (N.C.).
SWO 1 Motor 1 opening limit switch SWO1 (N.C.).
SWC 2 Motor 2 closing limit switch SWC2 (N.C.).
SWO 2 Motor 2 opening limit switch SWO2 (N.C.).
24V-
Accessories power supply output.
24V+
Tested safety device power supply output (photocell transmitter and safety edge transmitter).
24 Vsafe+
Output active only during operating cycle.
AUX 0
AUX 1
AUX 2
AUX 3
LOCK
Dimensions
Fuses
N° of combinations
Max.n° of transmitters that
can be memorized
Use cycle continuous
Operating
-20°C/+50°C
temperature range
Maximum motor
2x375 W
power 220-230V
1x750 W
Maximum motor
2x195 W
power110-120V
1x390 W
(110-120V) M1+M2+AUX0+AUX1+AUX2+AUX3+LOCK= 680W MAX @ T=+50°C
(220-230V) M1+M2+AUX0+AUX1+AUX2+AUX3+LOCK= 1300W MAX @ T=+50°C
Usable transmitter versions:
All ROLLING CODE transmitters compatible with
4) TUBE ARRANGEMENT Fi g. A
Description
solenoid latch output.
magnetic lock output.
Powered contact
110-120 / 220-230 V~
N.O. (80W MAX)
Powered contact
AUX0+
110-120 / 220-230 V~
AUX1+
N.O. (80W MAX)
AUX2=
NO contact
80W MAX
(MAX 110-120V~ 80W)
(MAX 220-230V~ 80W)
NO contact (Max 24V~) 10W MAX
Output for 12V sole-
10W MAX
noid lock:
see Fig. B
see Fig. C
4 billion
63
continuous 1 min. ON/
2 min. OFF
-20°C/+55°C -20°C/+50°C
2x250 W 2x650 W
1x500 W 1x750 W
(MODEL ECB)
1 min. ON/
2 min. OFF
-20°C/+55°C
2x500 W
1x750 W
