Field Settings Table - Rotex RKHBRD011AAV1 Manuel D'utilisation

NOTE When running through the field settings you may
notice that there are some more field settings as there
are mentioned in the "Field settings table" on page 15.
These field settings are not applicable and may not
be changed!

Field settings table

First Second
code code Setting name
0 Remote control setup
03 Status : space heating schedule timer mode
1 Automatic storage timing for domestic water heating
00 Status: night time storage
01 Night time storage start time
02 Status: day time storage
03 Day time storage start time
2 Automatic setback function
00 Status: setback operation
01 Setback operation start time
02 Setback operation stop time
3 Weather dependent set point
00 Low ambient temperature (Lo_A)
01 High ambient temperature (Hi_A)
02 Set point at low ambient temperature (Lo_Ti)
03 Set point at high ambient temperature (Hi_Ti)
4 Disinfection function
00 Status: disinfection operation
01 Disinfection operation day selection
02 Disinfection operation start time
5 Automatic setback and disinfection set point
00 Set point: disinfection operation temperature
01 Disinfection operation time duration
02 Leaving water setback temperature
03 Room setback temperature
8 Option setup
03 Status: low noise level
b Domestic hot water set points
00 Set point: reheat minimum temperature
01 Set point: reheat maximum temperature
02 Status: weather dependent domestic water
heating
03 Set point: storage temperature
Operation manual
15
Installer setting at variance with default value
Date Value Date
Default
Value value Range
1 (ON) 0/1
1 (ON) 0/1
1:00 0:00~23:00
0 (OFF) 0/1
15:00 0:00~23:00
1 (ON) 0/1
23:00 0:00~23:00
5:00 0:00~23:00
–10 –20~5
15 10~20
70 25~80
45 25~80
1 (ON) 0/1
Fri Mon~Sun
23:00 0:00~23:00
70 60~70
10 5~60
5 0~10
18 17~23
1 1~3
35 35~65
45 35~75
1 (ON) 0/1
70 45~75
RKHBRD011~016AAV1+Y1
Indoor unit for air to water heat pump system and options
Step Unit
— —
— —
1:00 hour
— —
1:00 hour
— —
1:00 hour
1:00 hour
1 °C
1 °C
1 °C
1 °C
— —
— —
1:00 hour
5 °C
5 min
1 °C
1 °C
1 —
1 °C
1 °C
— —
1 °C
4PW55803-1
