Domestic water heating

Domestic water heating can be done through several standard
operation modes:
• Automatic storage: by field setting, once during night and/or
once during the afternoon the water is heated till storage set
point.
• Manual storage: if due to special circumstances, production
of hot water (till storage set point) is needed immediately
(1 time), this function can be used.
• Reheat: the reheat function can be activated next to or
separate from the automatic storage operation if the user
wants to keep the domestic hot water tank at the minimum
reheat temperature.
Next to the standard domestic water heating operation modes, it is
also possible to freely program the domestic water heating operation
through the schedule timer (refer to "Programming quiet mode or
domestic water heating" on page 13). Then the mode is switched on
or off at a scheduled time. Five actions can be programmed per
mode. These actions are repeated daily (additional schedule of
storage on top of the automatic day and night storage functionality).
NOTE Remark that only the time when domestic water
heating must start and stop can be programmed
in the schedule timer. When domestic water
heating is enabled, the water will be heated till
storage set point. The storage set point is set
through field setting.
For energy-saving reasons, keep hours with low
electricity cost tariffs in mind when programming
the schedule timer for domestic water heating.

Quiet mode

Refer to "Programming quiet mode or domestic water heating" on
page 13.
Switch the mode on or off at a scheduled time. Five actions can be
programmed per mode. These actions are repeated daily.
NOTE If the auto restart function is disabled, the
schedule timer will not be activated when power
returns to the unit after a power supply failure.
Press the pr button to enable the schedule timer
again.
When power returns after a power supply failure,
the auto restart function reapplies the user
interface settings at the time of the power supply
failure (if time is shorter than 2 hours). It is
therefore recommended to leave the auto restart
function enabled.
The programmed schedule is time driven.
Therefore, it is essential to set the clock and the
day of the week correctly.
Refer to "Setting the clock" on page 4.
When the schedule timer is not enabled (p icon
not displayed), schedule timer actions will not be
executed!
The programmed actions are not stored according
to their timing but according to the time of
programming. This means that the action that was
programmed first gets action number 1, even
though it is executed after other programmed
action numbers.
Operation manual
11

Programming and consulting the schedule timer

Programming the schedule timer is flexible (you can add, remove or
alter programmed actions whenever required) and straightforward
(programming steps are limited to a minimum). However, before
programming the schedule timer, remind:
Familiarize yourself with the icons and the buttons. You will need
them when programming. Refer to "Remote controller buttons
and icons" on page 3.
Fill out the form at the very end of this manual. This form can
help you define the required actions for each day. Keep in mind
that:
- In the space heating program, 5 actions can be programmed
per weekday. The same actions are repeated on a weekly
basis.
- In the domestic water heating and quiet mode program, 5
actions can be programmed per mode. The same actions are
repeated on a daily basis.
Take your time to enter all data accurately.
Try to program the actions in a chronological way: start with
action 1 for the first action and end with the highest number for
the last action. This is not a requirement but will simplify the
interpretation of the program later.
If 2 or more actions are programmed for the same day and at the
same time, only the action with the highest action number will be
executed.
Example:
Programmed actions
Time Temperature
(hour) (°C)
1 16:00 — 22
2 18:00 — OFF
3 08:00 — 23
4 06:00 — 21
5 18:00 — 26
You can always alter, add or remove the programmed actions
later.
Indoor unit for air to water heat pump system and options
Executed actions
Time Temperature
(hour) (°C)
1 06:00 — 21
2 08:00 — 23
3 16:00 — 22
4 18:00 — OFF
