3707 - 3907 - 3907 L, M, H - 3907/18 - 3907/18 L, M, H
3707/10 - 3707/10 L, M, H - 3907 W - 3907 W L, M, H

Controls, indicators and connections

A. Vacuum gauge
B. Main switch (on "I" - off "0")
C. Reverse phase indicator (only for L - M - H versions)
D. Warning light indicating thermic intervention
E. Machine electrically powered indicator
F. Phase inverter
G. Electric filter shaker start button (optional)
H. Stop button
I. Start button
L. Hour counter
M. Visual level gauge
N. Castor brakes
O. Inlet
P. Container release
Q. Filter chamber
R. Dust container
S. Main filter shaker knob

Inspections prior to starting

Inlet (F)
Prior to starting, check that:
■ The filter is installed;
■ All latches are tightly locked;
■ The vacuum hose and tools have been correctly fitted
into the inlet (F);
Do not use the device if the filter is faulty.
GB
C65
Figure 4
Figure 5

Starting

Castor brakes (E)
Start switch (B)
Lock the castor brakes (E) before starting the vacuum cleaner.
■ Turn the switch (B) to "I" position to start the vacuum
cleaner.
■ Turn the switch to "0" position to turn the vacuum cleaner
off.
■ If the vacuum cleaner has been working and then stops
and the indicator light (C - Fig. 4) comes on, or if the
vacuum cleaner motor turns in the wrong direction, turn
it off and turn the inverter (F)

Emergency stopping

Turn the main switch to "0" position.
8
Figure 6
