32
Specifications
Audio
Total Harmonic Distortion
Intermodulation Distortion (60 Hz : 7 kHz, 4:1)
Frequency Response
Analog Bypass
Digital Input
Signal to Noise Ratio (A-weighted)
Analog Bypass
Digital Input
Input Sensitivity/Impedance
Line Level
Balance Level
Phono Level
Preamp Output Level
Line Level
Balance Level
Channel Separation (at 10k Hz)
Digital Audio
Video
Input Resolutions
Output Resolution
Color Space Support
Deep Color Support
HDMI Inputs/Outputs
General
Power Consumption
Power Requirements (AC)
BTU
Dimension (W x H x D)
Front Panel Height
Weight
When sizing openings in custom cabinets, measure the unit to be installed and/or allow at
least 1mm clearance on all sides for unit to unit tolerances. All specifications are accurate
at the time of printing. Rotel reserves the right to make improvements without notice.
Rotel and the Rotel Hifi logo are registered trademarks of The Rotel Co., Ltd. Tokyo, Japan.
< 0.005%
< 0.005%
10 Hz - 100k Hz, ± 1.5 dB
10 Hz - 20k Hz, ± 0.3 dB
112 dB
112 dB
250 mV/100k ohms
500 mV/100k ohms
3.2 mV/47k ohms
1.0 V
2.0 V
> 75 dB
LPCM (up to 192kHz, 24-bit)
Dolby
®
Digital, Dolby
®
Digital EX,
Dolby
®
TrueHD,
Dolby
®
Digital Plus,
DTS Digital Surround™,
DTS Digital Surround 96/24™,
DTS Digital Surround ES™,
DTS Digital Surround ES 96/24™
DTS-HD High Resolution Audio™.
DTS-HD Master Audio
TM
.
480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p 24Hz,
3D, 4K, UHD
480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p 24Hz,
3D, 4K, UHD
sRGB, YCbCr 4:2:2, YCbCr 4:4:4
24-bit, 30-bit, 36-bit
Version 1.4, support up to 4K
resolution pass-through and
Audio Return Channel.
45 watts
0.5 watt (standby)
120 volts, 60Hz (USA version)
230 volts, 50Hz (EC version)
137 BTU/h
431 x 188 x 416.8 mm
17 x 7
2
/
x 16
2
/
in
5
5
4U / 177 mm / 7 in
12 kg / 26.46 lbs
RSP-1582 Surround Sound Processor
"
Made for iPod," and "Made for iPhone," means that an electronic accessory
has been designed to connect specifically to iPod or iPhone, respectively, and
has been certified by the developer to meet Apple performance standards. Apple
is not responsible for the operation of this device or its compliance with safety
and regulatory standards. Please note that the use of this accessory with iPod,
or iPhone may affect wireless performance.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple
Inc., registered in the U.S. and other countries.
