Installing The Wall Bracket; Changing Batteries - Becker CentronicPLUS EC541 PLUS Notice De Montage Et D'utilisation

Installing the wall bracket

Wall bracket
Wall bracket
mounting plate

Changing batteries

You will find the appropriate battery type in the "Technical
data" chapter.
2
3
1
4
Unlocking mechanism
Change the batteries within a minute and
do not press any buttons in the process. After
the batteries are inserted, the LED ring of the
transmitter indicates the current battery
charge for a short time. When the LED ring is
blue and 100% full, the battery is fully
charged and when the LED ring is 50% full,
the battery charge is half, and so on.
1. Open the cover of the battery compartment.
2. Take out the batteries.
3. Insert the new batteries correctly.
4. Close the cover on the battery compartment.
• Before installation in the de-
sired installation position,
check that the transmitter and
receiver are functioning prop-
erly.
• Fix the bracket to the wall using
the two enclosed screws.
23 - en
