Switch-on sequence
16. If necessary, adjust more
parameters
After parameter setting:
17. Setpoint selection
18. Enable the controller.
19. The drive should now be running at
e.g. 30 Hz
L
E. g. JOG frequencies (C0037,
C0038, C0039), deceleration time
for quick stop (QSP) (C0105) or
motor temperature monitoring
(C0119)
E.g. via potentiometer at terminals
7, 8, 9
d c b
Πj g f k i h PS
‚ m n o
p
q r
Hi
Lo
EDK82EV222 DE/EN/FR 6.0
Commissioning
Vector control
Note
Terminal X3/28 = HIGH
If the drive does not start,
e a
u
press
Hz
7
in addition
37
