Troubleshooting

Most difficulties in audio systems are the result of incorrect
connections, or improper control settings. If you encounter problems,
isolate the area of the difficulty, check the control settings, determine
the cause of the fault and make the necessary changes. If you are
unable to get sound from the RCD-1520, refer to the suggestions for
the following conditions:

Power Indicator Is Not Lit

The Power Indicator and the basic items in the Display window should
be lit whenever the RCD-1520 is plugged into the wall power outlet
and the Power button is pushed in. If it does not light, test the power
outlet with another electrical device, such as a lamp. Be sure the
power outlet being used is not controlled by a switch that has been
turned off.

Fuse Replacement

If another electrical device works when plugged into the power outlet,
but the Power Indicator and the Display still will not light when the
RCD-1520 is plugged into the wall outlet, it indicates that the internal
power fuse may have blown. If you believe this has happened, contact
your authorized Rotel dealer to get the fuse replaced.

No Sound

Check the cables between the RCD-1520 and the amplifier inputs
to be sure they are connected properly. Be sure the amplifier input
that the RCD-1520 is selected. Be sure the tape monitor system of
the amplifier has not been activated. Check the wiring between the
amplifier and the speakers.

Specifications

Total Harmonic Distortion + Noise
Intermodulation Distortion
Frequency Response
(±0.5 dB)
Channel Balance
Phase Linearity
Channel Separation
Signal to Noise Ratio
Dynamic Range
Digital to Analog Converters
Speed Accuracy, Wow & Flutter
Maximum Audio Line Output
Output Impedance
Digital Output Level
(coax)
Digital Output Impedance
Power Requirements
USA Version
European Version
Power Consumption
Dimensions
(W x H x D)
Front Panel Height
(for rack mount)
Weight
(net)
All specifications are accurate at the time of printing. Rotel reserves the right to
make improvements without notice.
Rotel and the Rotel HiFi logo are registered trademarks of The Rotel Co, Ltd.,
Tokyo, Japan.
11
0.0045% @ 1kHz
0.0045% @ 1kHz
20-20,000 Hz
± 0.5 dB
± 0.5 degree
> 98 dB @ 1kHz
> 100dB
> 96 dB
Wolfson
Quartz Crystal Precision
2V RMS
100 Ohms
0.5 Volt, Peak to Peak
75 Ohms
AC 120V, 60 Hz
AC 230V, 50 Hz
20 Watts
17 x 4 x 12 5 / inches
8
431 x 99 x 320 mm
2U / 3 1 / inches / 88.1 mm
2
6.5 kg, 14.3 lb.
