R
- Lubricate the beads of the PAX tyre (R) and the surface of the support (S) that will come
into contact with the rim with standard lubricant for vehicle wheel mounting fig. 43
IMPORTANT
When lubricating the tyre interior with the special PAX System Gel of the mechanical
support, be careful not to touch the beads with that gel, since the beads are to be
lubricated with standard tyre lubricant
- Insert the Support (S) inside the tyre (R) fig. 44
- Use the special levers fig. 45
Make sure the orientation of the rest (S) is correct when introducing it into the
tyre, as described in Fig. 46 for standard, and in fig.46a for Clipé.
- Lubricate the bead housings on the rim (areas indicated with the letter T in fig. 47)
- Introduce the tyre-rest assembly on the rim fig. 47
30
S
T1
T
41
43
WARNING
42
44
