WOLFF ROBO-STRIPPER Traduction Du Mode D'emploi Original page 22

3.0 Installation
► Preparing transport:
Remove all weights from the Machine
The loading and unloading of the machine via ramps
should always be done backwards in order to avoid
tilting over the drive wheels.
The maximum ramp angle is 15 °.
3.1 Installing/removing additional weights
► 1 - 4 additional weights (15) can be
installed on the impact .
An additional weight weighs 22 kg.
The additional weight (15) is set on the frame of the
impact and fixed by the star-shaped screws
(2x item 5).
The weights are positioned over the holes (26) in
the frame or over the recess in the underlying
weight and the pins on the installed weight.
Make sure that the star-shaped screw does not
prevent the next weight from being installed.
► The additional weight (1) of the drive unit
is also fastened using a star-shaped screw (5)
and positioned over the holes in the frame of the
drive.
Properly tighten all star-shaped screws with
the provided spanner fig. F to prevent any
unnecessary vibrations.
Wolff GmbH & Co KG | D-74360 Ilsfeld | Ungerhalde 1 | Fon: +49 (0)7062-91556-0 | Fax: +49 (0)7062-91556-41 |
3.2 Installation Handel
The machine can be moved/transported with
and without a power supply.
► The following measures must be performed in
the specified order for the transport fig. G:
► Handle with transport rollers must be installed.
► The blade must be removed.
► Move the front carriage out by actuating the selector
key (30) fig. B until the drive wheels lift off the
ground (20).
► Loosen the straight bracket (8) on the wheels (29)
of the rear transport carriage (4).
► The following measures must be performed in the
specified order for transport with a power supply,
e.g. moving over a ramp, fig. J:
► Handle with transport rollers must be removed.
► The blade must be removed.
► Move the carriage (18) out by actuating the selector
key (30) fig. B until the drive wheels.
Lift up the the Swinger from The Bottom with the Blade
Holder.
Note: Manoeuvring a curve is only possible to a
limited extent, since the wheels on the front
carriage (18) cannot be steered.
► To move it to the working position fig. J, the
following measures must be performed in the
specified order:
► Move the carriage (18) by completely pressing in the
selector key (30) fig. B.
must not make contact with the floor.
They are only for transporting the machine.
► Handel with transport rollers should be removed.
www.wolff-tools.de
When working, the carriage wheels
