Dometic
3

Fitting the blind

➤ Before installing the blind, check whether there is enough space for the
blind.
The guide rails can be shortened if necessary (see chapter "Shortening
the guide rails" on page 18).
Fit the roller blind cassettes together (fig. 2, page 4)
➤ Align the individual parts as shown.
You must align the mortise ends with the short distance to the slots (4)
with the tenons of the blackout blind.
➤ Fit the two roller blind cassettes (1) and (2) and the two guide rails (3) to-
gether to form a closed frame:
– Thread the handle strip (5) of the blinds into the guide rails.
– Insert the tenons (6) into the mortises (7).
Fixing the blind
I
NOTE
You can attach the blackout on top and the flyscreen at the bottom
of the blind, as well as vice versa.
➤ Align the frame as follows on the window (fig. 3, page 5):
– The distance to the rubber profile of the window on the left and on the
right as well as on top and at the bottom must be same.
– The roller blind cassettes must run parallel to the upper and lower edg-
es of the window.
– The guide rails must be at right angles to the roller blind cassettes
I
NOTE
If the guide rails are too long, they can be shortened (see chapter
"Shortening the guide rails" on page 18).
➤ Mark the fixing holes in the support covers on the wall (fig. 4, page 5).
A
NOTICE!
 If the screws supplied do not hold in the wall, you must use
plugs suitable for the wall construction.
 Make sure you do not drill through the wall.
EN
Fitting the blind
17
