SPECIFICATIONS/ASSEMBLY

SPECIFICATIONS

S
Height at Sling Hook-up
P
Knob MAXIMUM:
E
C
Height at Sling Hook-up
I Knob MINIMUM:
F
Base Width OPEN:
I
Base Width CLOSED:
C
Base Height (Clearance):
A
Base Length:
T
I
Overall Height:
Overall Length:
O
Overall Width:
N
S
Caster Size FRONT:
/ Caster Size LOCKING REAR:
A
Sling Options:
S
Sling Material:
S
Weight Capacity:
E
Weight:
M
Shipping Weight:
B
Battery:
L
Y
Charger Input:
Charger Output:
Charging Time:
Audio Low Battery Alarm:
Motor Safety Devices:
** Approx. Lifts per
Charge:
Warranty (Electric/
Electronics):
Emergengcy Stop Button:
*
PATIENT SLINGS:
Width
Length
** Varies dependent upon load and stroke.

ASSEMBLY

ATTACHING MAST TO BASE
(FIGURE 1)
1. Lock the rear swivel casters. Refer to LOCKING/UN-
LOCKING THE REAR SWIVEL CASTERS in this
section of the manual.
Stand Up Lift
66-inches
40-inches
37-inches
26-inches
4.5-inches
35.5-inches
49-inches
39-inches
25.8-inches
3-inches
5-inches
*Standing or Transport
Polyester
350lbs.
108lbs.
135lbs.
24 VDC (RECHARGEABLE)
100 - 240 VAC
29.5 VDC
Maximum 6 Hours
YES
Anti-Entrapment
**100-200 Cycles per
Charge
1 Year
YES
STANDING TRANSPORT
36.0-inches 38.5-inches
13.0-inches 36.0-inches
2. Remove the hex bolt, nut and washer, that are located
in the U-shape cut-out of the base.
3. Position the mast in an upright position and place the
mast onto the U-shaped cut-out of the base.
4. Insert hex bolt with washers through the base and
mast. Secure with nut.
WARNING
The mast may be removed from the base for stor-
age or transporting. Each time mast is removed
and returned to base, the mast MUST be properly
secured to the base.
Mast
Hex Bolt
FIGURE 1 - ATTACHING MAST TO BASE
ATTACHING ELECTRIC ACTUATOR
TO MAST (FIGURE 2)
1. Remove the top nut, top bolt, bracket and bushing
from the lift arm mounting bracket.
2. Position the electric actuator in the lift arm mounting
bracket as shown in FIGURE 2.
3. Reinstall top nut, top bolt, bracket and bushing into lift arm
mounting bracket and electric actuator. Tighten securely.
CAUTION
DO NOT overtighten mounting hardware. This will
damage mounting brackets.
Lift Arm
Mounting
Bracket
FIGURE 2 - ATTACHING ELECTRIC ACTUATOR TO MAST
6
Washer
Nut
U-Shaped
Cut-out
Top Nut
Bracket
Bushing
Electric
Actuator
Top
Bolt
