MACHINE OVERVIEW

1
2
3
4
5
6
7
8
9
10
24 25
1. CUTTING HANDLE
2. LASER GUIDE ON / OFF SWITCH
3. REAR CARRY HANDLE*
4. TRENCH STOP
5. QUICK RELEASE HOLD DOWN CLAMP*
6. SLIDING FENCE
7. HEX KEY STORAGE
8. MACHINE TABLE EXTENSIONS
9. FRONT CLAMP HOLES
10. MOUNTING HOLE (X4)
11. BLADE GUARD LOCKING TRIGGER
12. BLADE ROTATION INDICATION ARROW
13. UPPER BLADE GUARD
14. CUTTING HEAD
15. BLADE
*Supplied as original equipment on the R255SMS-DB+.
Non-North American models only.
†
26 27
16. LOWER BLADE GUARD
17. TABLE TOP
18. ROTARY TABLE
19. FRONT CLAMP*
20. TABLE INSERT
21. MITRE HANDLE LOCKING KNOB
22. POSITIVE STOP LOCKING LEVER
23. MITRE ANGLE SCALE
24. CABLE GRIP COMPONENT
(FITTED TO THE REAR CABLE GUIDE CLAMP)
25. DUSTPORT ADAPTER*
†
26. STANDARD HOLD DOWN CLAMP
27. DUST BAG*
28. ARBOR COVER
North American models only.
◊
230v models only.
‡
15
11
12
13
14
15
16
17
18
19
20
21
22
23
28
†
‡
◊
EN
