29. ON / OFF TRIGGER SWITCH
30. CARBON BRUSH HOLDER
31. DUST EXTRACTION PORT
32. REAR SLIDING CARRIAGE
33. SLIDE LOCKING SCREW
34. REAR CABLE GUIDE CLAMP
35. BEVE L LOCK HANDLE
36. LEFT 33.9˚ BEVEL PIN
37. MAINS POWER CABLE
38. ARBOR LOCK BUTTON
www.evolutionpowertools.com
44 45
39. DRIVE BELT COVER
40. CUTTING HEAD LOCKING PIN
41. FRONT CABLE GUIDE CLAMP
42. M5 X 20mm SELF TAPPING CAP SCREW X1
43. M6 X 16mm SOCKET HEAD SCREW X4
44. M6 X 12mm HEAD SECURING SOCKET HEAD
SCREWS X2
45. ANTI-VIBRATION SPRING
(FITTED TO ITEM '33' - THE SLIDE LOCKING
SCREW)
46. 6mm & 4mm DUAL ENDED HEX KEY
