Note: Use the smaller 'V' Chamfer Groove for a shallower chamfer
and the larger groove for a deeper chamfer.
2. Power the planer ON and run the planer along the corner edge.
IMPORTANT: Always test out first on a scrap piece of material.
Lift the tool from the workpiece before releasing the ON/OFF
Trigger Switch and powering OFF.
Accessories
• A range of accessories and consumables including blades,
additional clamps, and personal protective equipment is
available from your Triton stockist.
• Spare parts can be purchased from your Triton dealer or online
at www.toolsparesonline.com.
Maintenance
WARNING: Ensure the tool is switched OFF and the plug is
removed from the power supply before making any adjustments or
maintenance procedures.
General inspection
• Regularly check that all the fixing screws are tight. They may
vibrate loose over time.
• Prior to each use, inspect the supply cord of the tool for damage
or wear. This advice also applies to extension cords used with
this tool.
• If replacement of the supply cord is necessary, this must be
done by the manufacturer or their agent in order to avoid a
safety hazard.
Drive belt replacement
• It is recommended that leather gloves are worn when changing
the belt, in the event of hands coming into contact with the
blades.
1. To replace the Drive Belt (18), remove the three crosshead
screws that secure the Drive Belt Cover (9).
2. Remove the damaged/worn belt and use a soft brush to clean
the pulleys and the surrounding area.
Note: Wear eye protection when cleaning out the pulley area.
3. Place the new belt over the bottom pulley. Half-fit the other end
of the belt on the top pulley then roll the belt in place while
turning the pulley.
4. Check that the belt runs evenly by manually turning the belt.
5. Replace the cover and the fixing screws.
Connect the tool to the power supply and run the planer for
a minute or two to ensure the motor and belt are operating
correctly.
Brush replacement
• It is recommended that leather gloves are worn when changing
the brushes, in the event of hands coming into contact with the
EN
blades.
1. To replace the brushes, remove the three crosshead screws that
secure the Brush Access Cover (10).
2. Disconnect the cables from the brushes (Image A).
3. Using a screwdriver, pop out the brushes from the holding
positions (Image B).
12
4. Use a flat tipped screwdriver to open out the holding flap on the
brush casing (Image C) then remove the brush (Image D).
5. Insert the new brush correctly with the casing, ensuring the
groove on the carbon is the same side as the alignment fork
(Image E).
6. Press the brush spring in and close the holding flap of the case (F).
7. Re-insert the new brush with its case into the holding position
and reconnect the cables.
8. Re-attach the Brush Access Cover and secure with the crosshead
screws.
Cleaning
WARNING: ALWAYS wear protective equipment including eye
protection and gloves when cleaning this tool.
• Keep your tool clean at all times. Dirt and dust will cause
internal parts to wear quickly, and shorten the device's service
life.
• Clean the body of your machine with a soft brush, or dry cloth.
• Never use caustic agents to clean plastic parts. If dry cleaning
is not sufficient, a mild detergent on a damp cloth is
recommended.
• Water must never come into contact with the tool.
• Ensure the tool is thoroughly dry before using it.
• If available, use clean, dry, compressed air to blow through the
ventilation holes (where applicable).
Lubrication
• Lubricate all moving parts with a suitable lubricant spray at
regular intervals.
Storage
• Store this tool carefully in a secure, dry place out of the reach of
children.
• Store out of direct sunlight.
Contact
For technical or repair service advice, please contact the helpline on
(+44) 1935 382 222
Web: www.tritontools.com
UK Address:
Toolstream Ltd.
Boundary Way
Lufton Trading Estate
Yeovil, Somerset
BA22 8HZ, United Kingdom
EU Address:
Toolstream B.V.
Hogeweg 39
5301 LJ Zaltbommel
The Netherlands
