4b: Connecting the video components

How to hook up your
components
This section describes how to hook up your
components to this receiver. Before you begin,
refer to "Component to be connected" below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to "5: Connecting the antennas
(aerials)" (page 35).
Component to be connected
TV monitor
With HDMI jack
DVD player, DVD recorder
Satellite tuner
VCR
Camcorder, video game, etc.
26
GB
Video input/output jacks to be
connected
The image quality depends on the connecting
jack. Refer to the illustration that follows.
Select the connection according to the jacks on
your components.
Page
19, 31
Digital
27
29-30
31
32
32
Analog
High quality image
