HARDWARE CONTENTS
AA BB
Wood Dowel Metal Dowel Locking Nut Magnetic
Qty. 24 Qty. 22
II JJ
M3 x 10 mm
Screw
Qty. 18
M5 x 40 mm
Screw
Qty. 4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
WARNING
• Do not load this unit with more than 30 lbs.
• Safely discard all packing material.
• Keep small part away from children.
•
The assistance of another person may be requried to help install this unit.
CAUTION
• Take care when moving the product and never drag the pieces cross the floor as this will cause
damage to the joints.
(not shown actual size)
CC DD
Catch
Qty. 22 Qty. 1
LL
KK
Shelf Door
Support Hinge
Qty. 4 Qty. 4
EE FF
M2.5 x 14 mm M4 x 18 mm
Screw Screw
Qty. 2 Qty. 2
MM NN
M2.5 x 10 mm
Screw
Qty. 27
M3.5 x 40 mm
Screw
Qty. 2
3
GG HH
Handle Door
Catch Plate
Qty. 2 Qty. 2
OO
PP
Anchor
Allen Key
Qty. 2
Qty. 1
