Operating Instructions
WARNING! Always keep the nozzle in contact with the container being filled
during the filling process to minimize the possibility of static electricity build up.
1.
If so equipped, reset meter to "0" (do
not reset while in use as this will cause
damage to the meter).
2.
Remove dispensing nozzle from nozzle
boot.
3.
Move the switch lever to the "ON"
position to power the pump (figure 5).
4.
Insert the dispensing nozzle into the
container to be filled.
5.
Operate the nozzle to dispense fluid;
release nozzle when the desired
amount of fluid has been dispensed.
Padlocking
Your Fill-Rite pump nozzle can be
padlocked to the pump for added
security. With the pump turned off,
and the nozzle in the stored position,
a padlock can be inserted through the
locking link and the nozzle handle.
The locking link is located on the
nozzle side of the pump, and can be
pivoted into position to work with a
variety of nozzles (Figure 7).
6.
7.
Figure 6
"OFF" position
12
Figure 5
"ON" position
Move switch lever to the "OFF"
position (Figure 6) to turn off the
pump.
Remove the dispensing nozzle
from the container being filled
and store it in the nozzle boot.
Figure 7
Locking Link
