Troubleshooting

Problem
Which surfaces
are suitable?
The TV desk
mount is hard to
align.
Other questions
Tab. 18: Troubleshooting
8 Specifications
Physical size
TV diameter
VESA
Load
Tilting angle
Swivel angle of
each swivel arm
Rotation angle
Desk distance
(middle of flat
screen)
Dimensions
Weight
Tab. 19: Specifications
9

Information for VESA standard

To harmonize attachment options of monitors, TV devices and their stands and
wall brackets in a user-friendly manner, VESA (Video Electronic Standard
Assoziation) defined 3 standards for the applications mentioned above. Using
the relevant VESA standard specified on your display unit, or in its user's
manual, and the specifications in Chapter Specifications in this manual you are
able to define the possible points of attachment. Some models allow for an
infinitely variable individual attachment (e.g. 300 x 300 mm for Sony TVs).
VESA Class
MIS-D
MIS-E
MIS-F
Tab. 20: Information for VESA standard
Help
>>
Massive wood plates,
>> Working plates and
Metal plates with a thickness of 10-40 mm
>>
>> Loosen the joints a little bit.
>> Due to the screen size, the maximum swivel angle
may be lower than described.
>> Contact your dealer.
Specification
13-23
75x75 / 100x100
max. 2x8
+/-15
+/-15,
360
360
62-330
772x510x115
3.5
Hole distance for attachment of monitors
75x75 / 100x100mm
200x100 / 200x200mm
400x200 / 400x400 / 600x200 / 600x400 / 800x400mm
Unit
" / Inches
mm
kg
°
°
°
mm
mm
kg
