Adjustment of the actuator
"Adjustment run" of the actuator "Aktor MH/MD CON B"
After having created the radio connection, the actuator has to be adjusted to the valve of
your radiator. This process is called "adjustment run".
1. Remove the casing cover of the actuator (during installation).
2. Keep the "teach in"/adjustment button pressed for at least 2 seconds to launch the
"adjustment run". The valve is now closed by the actuator.
"Teach in"/adjustment button
LED info
(visible even
when the casing
cover is closed)
Completion of the process is signalized by a triple green flashing (slowly) of both
LEDs. The operational readiness is displayed by the following symbols on the
"R-Tronic" display:
This display will appear for this first time after the next transmission interval (cycle:
150 seconds). It signalizes the start of the heating period according to the "R-Tronic"
settings (radiator valve is opened again).
3. Mount the casing cover onto the actuator until it engages audibly.
NOTE regarding basic setting of heating profiles
One of three standard heating profiles can be activated via the Auto/Manu-button for a
first basic setting of the system.
When putting the "R-Tronic" into operation, the setting PROFILE ON will be active
constantly and adjust the room temperature to 20 °C.
Select PROFILE OFF for a constant reduction of the room temperature to 17°C.
If you do not wish a constant heating or setback operation according to only one setting,
select PROFILE DAY/NIGHT. The room temperature will be reduced to 17°C between
22.00 h and 06.00 h and be adjusted to a "comfort temperature" of 20°C during the day.
More information can be obtained from the detailed operating instructions!
