Connecting to Component Video
Equipment
Using a Component Cable
Use a component cable when connecting to the
Component terminal and component video equipment
such as DVD players and DTV* decoders.
*DTV is an umbrella term used to describe the new
digital television system in the United States.
•
When connecting the projector to the
note
video equipment in this way, select
"Component" for "Source" menu.
Connecting by Using a HDMI
to HDMI Cable
Use an HDMI to HDMI cable when connecting
HDMI video equipments such as DVD players to
HDMI 1 or 2 terminal.
1
Connect an hDMi to hDMi cable to
the projector.
2
Connect the above cable to the
video equipment.
•
Select the input signal type of
note
the video equipment.
All manuals and user guides at all-guides.com
To analog component
output terminal
DVD player, BluRay player, or
DTV* decoder
The component jack for a DVD and so forth may be
indicated with Y, CB or CR. Connect each jack as
shown below.
Projector
DVD player or
DTV decoder
DVD player, BluRay player, or
DTV* decoder
To HDMI output
terminal
10
MICO 40-50-ST
MiCO 50
Component cable
(commercially
available)
Pr Pb Y
COMPOSITE S-VIDEO GRAPHICS RGB
HDMI 1 HDMI 2
COMPONENT
WIRED REMOTE
Y P P
b r
Y C C
b r
HDMI to HDMI cable
Pr
USB RS-232 COMPOSITE S-VIDEO
HDMI 1 HDMI 2
WIRED REMOTE
12V 12V
TRIG1 TRIG2
Pb Y
GR
COMPONENT
