Item Explanation
LEVEL INFO Displays the measurement
result for speaker level.
EXIT Exits the setting process
without saving the
measurement results.
3
Press V/v repeatedly to select the
parameter, then press
AUTO EQ type Explanation
FULL FLAT Makes the measurement of
frequency from each speaker
flat.
ENGINEER Sets the frequency
characteristics to a set that
matches that of the Sony
listening room standard.
FRONT REF Adjusts the characteristics of
all the speakers to match the
characteristics of the front
speaker.
OFF Set the auto calibration type
to off.
Tip
The size of a speaker (LARGE/SMALL) is
determined by the low characteristics. The
measurement results may vary, depending on the
position of the optimizer microphone and speakers,
and the shape of the room. It is recommended that
you follow the measurement results. However, you
can change those settings in the Speaker settings
menu. Save the measurement results first, then try to
change the settings if you want.
When you select "PHASE INFO"
You can check the phase of each speaker (in
phase/out of phase).
Press V/v repeatedly to select a speaker,
then press to return to step 1 in "To
confirm/save auto calibration when GUI
function is turned off."
Display Explanation
IN The speaker is in phase.
Display
OUT
.
– – –
Tip
Depending on the position of the sub woofer, the
measurement results for polarity may vary.
However, there will be no problems even if you
continue to use the receiver with that value.
Selecting a sound field type
For details on each sound field type, see
"Enjoying a pre-programmed sound field"
(page 62).
Press 2CH/A.DIRECT, A.F.D.,
MOVIE, or MUSIC repeatedly.
The selected sound field type appears on the
display.
You can also use the 2CH/A.DIRECT, A.F.D.,
MOVIE, or MUSIC buttons on the receiver.
Listening to the sound without
any adjustment (ANALOG
DIRECT)
Press 2CH/A.DIRECT.
You can also use 2CH/A.DIRECT on the
receiver.
Listening to the FM/AM radio
For details on the tuner function, see "Tuner
Operations" (page 82).
Explanation
The speaker is out of phase. The
"+" and "–" terminals of the
speaker may be connected the
other way around. However,
depending on the speakers,
"OUT" appears on the display
even though the speakers are
connected properly. This is
because of the speakers'
specifications. In this case, you
can continue to use the receiver.
No speakers are connected.
continued
