4a: Connecting the audio components

How to hook up your
components
This section describes how to hook up your
components to this receiver. Before you begin,
refer to "Component to be connected" below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to "5: Connecting the antennas
(aerials)" (page 38).
Component to be connected
Super Audio CD
player/ CD player
MD player
Tape deck, Analog disc turntable
22
GB
Page
With digital audio
output
With multi-channel
audio output
With analog audio
output only
With digital audio
output
With analog audio
output only
Audio input/output jacks to be
connected
The sound quality depends on the jack used.
Refer to the illustration that follows. Select the
connection configuration according to the
jacks of your components.
23
Digital
25
26
23
Notes
26 • When connecting optical digital cords, insert the
plugs straight in until they click into place.
• Do not bend or tie optical digital cords.
26
Tip
All the digital audio jacks are compatible with 32
kHz, 44.1 kHz, 48 kHz, and 96 kHz sampling
frequencies.
Analog
High quality sound
