Sony STR-DA5300ES Mode D'emploi page 112

x 12V Trigger
You can turn the receiver on/off in another
zone, or select various options for use of the
12V Trigger function, as explained below.
• OFF
Lets you turn off output of 12V triggers even
when the main receiver is turned on.
• ZONE
Lets you turn the output of 12V triggers on
or off based on whether the selected zone is
turned on or off.
• CTRL
Lets you turn the output of 12V triggers on
or off manually using the CIS command of
the IR remote.
• INPUT (for "Main" only)
Lets you turn on the output of 12V triggers
when the preset input is selected.
When you select "Input," the setting display
which sets each input trigger to on/off
appears. Press V/v to select the input, then
press to check the box.
• MAIN (for "Zone 2" and "Zone 3" only)
Lets you link operation of trigger in zone 2
or zone 3 to the main receiver.
Tips
• Even when this receiver is standby mode (press
?/1 on the remote to turned off this receiver), the
receiver in zone 2 or zone 3 remains turned on. To
turn off all receivers, press ?/1 and AV ?/1 on the
RM-AAL008 remote at the same time (SYSTEM
STANDBY).
• Only signals from components connected to the
analog input jacks are output through the ZONE 2
OUT/ZONE 3 OUT jacks. No signals are output
from components connected to only the digital
input jacks.
• When SOURCE is selected, the signals input to the
MULTI CHANNEL INPUT jacks are not output
from the ZONE 2 OUT or ZONE 3 OUT jacks
even when the multi-channel input is selected. The
analog audio signals of the current function are
output.
• When "Tuner" is selected; the same type of radio
station (FM/AM) selected in the main zone is set in
zone 2 and zone 3. However, you can select the
input other than "Tuner" in zone 2 and zone 3.
• When the receiver in the main zone is turned off, or
an input source other than "Tuner" is selected, you
can select a radio station from AM or FM in zone
112
GB
2. When the receiver in the main zone and zone 2
are turned off, you can select a radio station from
AM or FM in zone 3.
When two of the receivers in the main zone, zone 2
or zone 3 are turned off, you can select a broadcast
from FM/AM/XM/SIRIUS in one zone in which
the receiver is turned on.
Option menu parameter of zone
2/zone 3 operations
x RS-232C Control
• ON
The receiver can receive commands from the
RS-232C port.
• OFF
The receiver does not receive commands
from the RS-232C port.
About the IR REMOTE jack
You can operate the receiver without pointing
the remote toward the IR repeater of the
receiver if you connect an IR repeater (not
supplied) to the IR REMOTE jack.
Use an IR repeater when you install the
receiver in a place where signals from the
remote cannot reach.
STR-DA5300ES IR repeater
(not supplied)
RM-AAL008
