4
SPECIFICATION
4.1 ENGINE SPECIFICATION
TYPE:
Briggs & Stratton 6.5KW @ 1800
RPM camshaft speed, single
cylinder, 4stroke petrol (gasoline)
engine,
12 volt electric start and recoil
start
Model:
Vanguard 185467
Maximum Speed:
3000 RPM +/- 50 rpm
Camshaft rotation
1500 RPM (No load)
Idle Speed:
1500RPM +/- 50 rpm
Camshaft rotation
750 RPM
Oil Sump Capacity:
1.0 litres
Fuel:
Lead free petrol
Fuel Tank Capacity:
7.9 litres
4.2 MACHINE SPECIFICATION
Chassis:
Pressed steel welded fabrication.
Transmission:
Gearbox with half speed reverse
to heavy duty roller chains to
Landroll and cuttingcylinder.
Clutches:
Main centrifugal clutch.
Separate Landroll clutch.
Separate cylinder clutch.
Front roll:
One piece steel roll runningon
ball bearings.
Landroll:
3 piece cast iron with machine
cut gear differentialrunning in oil
bath, and expanding shoe brake.
Cutting cylinder:
All welded 6 or 9 knife, cylinder
running on ball bearings.
All manuals and user guides at all-guides.com
SAFETY, OPERATORS & MAINTENANCE MANUAL
296cc, with
Cutting ratio:
65 or 100 cuts / metre
Height of cut:
13- 35mm
Handles:
Tubular steel adjustable at top.
Grassbox:
Large capacity fibreglass tip-over
Cutting width:
91cm
4.3 DIMENSIONS
Width of cut:
0.91 metres
Overall width:
1.12 metres
Overall height:
1.27 metres
Overall length:
2.16 metres
Overall weight of
machine:
350Kg
GB-9
