Bitte beachten Sie
DEUTSCH
Die TFT-Schublade
Wir freuen uns, dass Sie sich für die TFT-
Schublade RC 24 entschieden haben.
Gültigkeit dieser Anleitung
Dieses Anwenderhandbuch gilt ausschließ-
lich für die TFT-Schublade Rc 24 mit
17"-Display und integrierter Tastatur.
Merkmale
–
Nur 1HE Einbauhöhe
–
Einbautiefe 600 bis 1 000 mm
–
17"-SXGA-Display mit Bildschirm-Menü
–
Display wird beim Zusammenklappen
automatisch stromlos geschaltet
–
Tastatur mit länderspezifischem Layout
–
Handballenauflage aus Moosgummi
–
Touchpad mit integrierter rechter
Mausklick-Funktion
–
Linke und rechte Maustasten
–
Integriertes Weitbereichsnetzteil
(100–240 VAC) mit IEC 320
Kaltgerätebuchse
–
Strom-Anschlusskabel
–
Standard HD15 Video Stecker
1.1
Allgemeine Hinweise
Urheberrecht
Alle Rechte an diesem Handbuch liegen
bei Knürr. Wiedergabe und Nachdruck
auch von Teilen dieses Handbuches sind
nur mit Quellenangabe gestattet.
Technischer Stand
Technischer Stand: 04/2009
Knürr behält sich das Recht vor, ohne
Vorankündigung
–
Konstruktions- und Bauteileverände–
rungen vorzunehmen, sowie anstelle
der angegebenen Bauteile äquivalente
andere Bauteile zu verwenden, die dem
technischen Fortschritt dienen,
–
Informationen dieses Handbuches zu
ändern.
Haftung
Knürr übernimmt keinerlei Gewähr für
die vollständige Richtigkeit der Angaben.
Ins besondere wird keine Haftung für Schä-
den übernommen, die aus unsach ge mäßer
Handhabung der Produkte entstehen.
4
Please read
ENGLISH
The TFT drawer
Thank you for choosing the TFT drawer
RC 24.
Validity of this manual
This user's manual applies exclusively to the
TFT Drawer Rc 24 with a 17" display and an
integrated keyboard.
Features
–
only 1U installation height
–
installation depth, 600 to 1 000 mm
–
17" SXGA display with screen menu
–
Display is automatically disconnected
from the power supply when it is closed
–
Keyboard with country-specific layout
–
support made of foam rubber for the heel
of the hand
–
touchpad with integrated right mouse-
click function
–
left and right mouse buttons
–
integrated wide-range power supply
(100–240 VAC) with IEC 320 mains con-
nector
–
power connection lead
–
standard HD15 video connector
General Information
Copyright
All rights to this manual are owned by
Knürr. Reproduction and reprinting of
this manual, in whole or in part, are permit-
ted only if the source of the information
is specified.
Technical status
Technical status of the manual 04/2009.
Knürr reserves the right
–
to modify the design or the components
or to use equivalent components
other than those shown where this serves
technical progress and
–
to modify the information contained
in this manual without prior notice.
Liability
Knürr can not accept responsibility for
the completeness and correctness of the
in formation. In particular, we accept no
liability for damages which result from
incorrect use or operation of the product.
A consulter imperativement
FRANÇAIS
Le tiroir TFT
Nous sommes heureux que vous ayez choisi
le tiroir TFT RC 24.
Validité du présent manuel
Le présent manuel utilisateur concerne
uniquement le tiroir TFT RC 24 avec écran
17" et clavier intégré.
Caractéristiques
–
Encombrement limité à 1HE
–
Profondeur de montage de 600 mm à
1 000 mm
–
Ecran SXGA 17" avec menu d'écran
–
Quand on rabat l'écran, celui-ci est mis
automatiquement hors tension
–
Clavier adaptés au pays concerné
–
Repose-main en caoutchouc mousse
–
Touchpad à fonction clic de souris droit
intégré
–
Touches souris gauche et droite
–
Bloc d'alimentation à large spectre
intégré (100 V–240 V CA) avec douille
d'appareil froide IEC 320
–
Cordon d'alimentation
–
Connecteur vidéo standard à fiches HD15
Consignes générales
Droits d'auteur
Tous les droits relatifs au présent manuel
reviennent à la société Knürr. Toute
reproduction ou réimpression intégrale ou
partielle du présent manuel est autorisée
uniquement avec indication des sources.
Etat technique
Etat technique 04/2009.
La société Knürr se réserve le droit, sans avis
préalable,
–
d'apporter des modifications relatives
à la construction et aux pièces, d'utiliser à
la pièces indiquées d'autres pièces équi-
valentes utiles aux progrès techniques,
–
de modifier les informations contenues
dans le présent manuel.
Responsabilité
Knürr ne donne aucune garantie en ce qui
concerne l'exactitude totale des indications.
Par ailleurs, aucune responsabilité n'est as-
sumée pour les dommages découlant d'une
utilisation non conforme des appareils.
