DIGITAL CABLE DIAGRAM
Wiring Diagram – Digital Cable with GPIOs
Signal Number
1
11
12
13
8
6
J3
+
5 -
4
14 +
-
15
VX222
User's Manual
9-pin
SubD
1
GPI OUT 1A
2
GPI OUT 1B
4
GPI OUT 2A
5
GPI OUT 2B
6
GPI IN 1
9
GPI IN 2
3, 7, 8
shield
XLR
3
2 J11
1 female
3
J12
2
1
male
v2
J10
female
AES/EBU
SYNC/IN 1
AES/EBU OUT
