APPENDICES

SCHEMATIC DIAGRAM

Layout

SW1
J 1
J 2
J 3

Jumper (SW1)

Position
ON
OFF

Headphone connector (J1)

(3.5 mm TRS female jack)
Contact
Sleeve
Tip
Ring
Nominal Input Level
+4 dBu
-10 dBV
Signal
Ground
Left channel
Right channel
VX222
User's Manual
VX222
Maximum Input Level
+22 dBu
+10 dBu
v2
v2
27
