Using power assisted pedalling
06
6. DISPLAY - INSTRUMENT "B"

6.a - Function buttons

T1. Display switching ON/OFF.
See paragraph "1" for how to turn the assist-
ed pedalling system on.
Briefly press the button to put the tool in
stand-by mode.
Briefly press it again to turn it back on.
T2. Lights switching on/off(if present and
connected)
- Short pressing: the light turns on.
- Short pressing: the light turns off.
T3. Display
T4. Increases the pedalling assistance level.
T5. Decreases the pedalling assistance level.
T6. Keep this button pressed for more than 3 sec-
onds to activate the push help function (max.
6km/h) until the button is released.
6.b - Display description
- The display shows various information de-
scribed in the next page.
- To set the unit of measurement of speed from
km/h to miles/h:
• Press button "T2" for three seconds.
• Press one of the buttons "+" (T4) or "-" (T5) to
select the unit of measurement.
• Press button "T2" for three seconds to con-
firm your choice.
- The main page offers the following
information:
a. "Light" symbol:
lights condition (if present).
b. Mode change
c. Displaying the pedalling assistance level
d. Speed
e. Battery charge level.
f. Unit of measurement (km/h > m/h)
g. System anomaly signal
EN_28
1
T5
T2
T6
a
c
d
e
g
T4
T3
T4
T1
T3
T5
b
f
