Assembly and Adjustments
04
-
Align the tip of the saddle so that it is pointing
towards the from of the bicycle.
-
Re-tighten the saddle support tube locking
collar (MAX tightening torque 8 Nm).
(fig. "34")
3.a - Regulating the saddle position
and angle
-
Loosen the saddle locking screws (using a 6
mm Allen key) (fig. "35").
-
Adjust the angle of the saddle as desired (fig.
"36").
-
Tighten the screws respecting the correct
torque values (see paragraph "4" - Section "03")
(fig. "37").
4. ADJUSTING THE BRAKE LEVERS
-
If you wish to adjust the position of the brake
levers:
The procedure described below is valid for
both brake levers.
· Loosen the lever locking screw (using a 5
mm Allen key) (fig. "38").
· Adjust the angle of the lever as desired (fig.
"39").
· Tighten the screws respecting the correct
torque values (see paragraph "4" - Section
"03") (fig. "40").
EN_16
5. ADJUSTING THE GEAR
CHANGE LEVER
-
If you wish to adjust the position of the gear
change lever:
· Loosen the lever locking screw (using a 5
mm Allen key) (fig. "41").
· Adjust the angle of the lever as desired (fig.
"42").
· Tighten the screws respecting the correct
torque values (see paragraph "4" - Section
"03") (fig. "43").
Ed. 1 - 03/2019
