MOTOR TYPE
< EC OK
OK OK
DIGITAL INPUT
< (NO) OK
OK OK
OUTPUT PULSES
< 4 OK
OK OK
PROGRAM C:1?
< NO YES
SI YES
YES
Program OK
>
<Press any key

7. OPERATION WITH TIMER RTC ECOWATT ACCESSORY AND PROSYS ECOWATT CONSOLE ACCESSORY

Acquiring the programming Schedule TIMER RTC ECOWATT offered and accessory, you will have access to functions described
in section 6 Operation with PROSYS ECOWATT accessory console, in addition to program the following:
• Up to three periods per day with desired set pointa
• Holiday period by scheduling date and start/end time and % over maximum speed

7.1. INSTALLATION

As shown in fi gure below, this accessory is an electronic component that must be installed inside the roof fan control box.
No modify
DIGITAL INPUT
< (NC)
Digital input:
- NC: Normally closed contact. The fan will pass to night mode when contact
Digital input:
is opened.
- NC: Normally closed contact. The fan will pass to night mode when
- NO: Normally open contact. The fan will pass to night mode when contact
is closed.
Press or to manually modify parameter that
displays the speed by J8 output (TACOM). It is advised
not to change.
Save parameters modified
Press any key to return to main screen
TIMER RTC ECOWATT
55
OK
