11 Operating the Lawn Mower
► Measure the following:
– Thickness a
– Width b
– Sharpening angle c
► If the minimum thickness or minimum width is
fallen below: replace the blade,
► If the sharpening angle is not correct: sharpen
the blade,
19.2.
► If anything is unclear: consult a STIHL special‐
ist dealer.
11 Operating the Lawn Mower
11.1
Holding and Guiding the Lawn
Mower
► Hold the handlebar with both hands so the
thumbs enclose the handlebar.
11.2
Setting the Cutting Height
Five cutting heights can be set:
– 30 mm = position 1
– 40 mm = position 2
– 50 mm = position 3
– 60 mm = position 4
– 70 mm = position 5
Setting the cutting height
► Stop the engine.
The blade must not be turning.
► Place the lawn mower on a level surface.
0478-111-9657-B
► Press lever (1) outwards towards the rear
wheel and hold in position.
► Move lever (1) to the desired position (2) and
19.2.
allow it to engage.
11.3
11.3.1
► Place the lawn mower on a level surface.
► Start the engine.
► Pull control bar for self-propulsion (1) fully in
the direction of the handlebar and hold so the
thumb encloses the handlebar.
The lawn mower starts moving.
11.3.2
► Release the control bar for self-propulsion.
► Wait until the lawn mower comes to a stand‐
still.
11.4
During mulching, the cut grass is chopped up
several times through a special air flow guidance
system in the mower blade area and then blown
back into the turf. The clippings remain on the
lawn surface where they partially decompose
and serve as a natural fertiliser. To ensure a per‐
fect, thick lawn, mulch regularly, removing one
third of the grass height.
Requirements for good mulching results:
– Frequency: at least twice a week in the spring
(main period of growth) and once a week in
the summer and autumn.
– Mow the lawn when dry if possible.
Switching the Drive On and Off
Engaging Self-propulsion
Disengaging Self-propulsion
Mulching
English
29
